Effective from 29 OCT 2026 to 31 JAN 2028 | Published on 01 OCT 2026

AIRAC AIP SUP 17/2026

  CONSTRUCTION CRANES AFFECTING HAMAD INTERNATIONAL AND DOHA INTERNATIONAL AIRPORTS

  Document Information

1.Validity, from: 2026/10/29 to: 2028/01/31
2.The following publications have been incorporated in this AIRAC AIP SUP and therefore cancelled:
Cancelled AIRAC AIP SUP: NIL Replaced AIRAC AIP SUP: 13/2026
3.The following NOTAMs are incorporated in this AIRAC AIP SUP. They will be cancelled by NOTAM.
Incorporated NOTAMs: NIL

  Operational Information

1  INTRODUCTION

1.1 The purpose of this AIP Supplement is to notify the operations of multiple cranes affecting Hamad International and Doha International airports.

2  CRANE DETAILS

2.1 Cranes affecting Hamad International and Doha International Airports.
Station/ Location/ Area NameIDCoordinates(1)Radius (m)Height (m)Affected AerodromeEnd Date of Operation
Doha portA-151251753.87N 0513307.50E.36m65m AMSLOTBD/OTHH31 Dec 2026
Hitlon Double Tree ProjectA-152251639.19N 0513306.89E - 251641.19N 0513312.37E - 251638.64N 0513313.52E - 251635.99N 0513310.31E - 251636.43N 0513308.13E - 251639.19N 0513306.89E.N/A70.89 AGLOTBD/OTHH15 Apr 2027
Al Mana ViewsA-159251700.84N 0513301.53E- 251659.45N 0513302.15E- 251658.27N 0513301.13E- 251658.48N 0513259.49E- 251659.88N 0513258.88E- 251701.06N 0513259.90E- 251700.84N 0513301.53E.N/A55.95m AGLOTBD/OTHH30 Jun 2027
Al Mana ViewsA-160251700.62N 0513303.87E- 251659.31N 0513304.69E- 251658.02N 0513303.87E- 251658.02N 0513302.21E- 251659.32N 0513301.39E- 251700.62N 0513302.22E- 251700.62N 0513303.87E.N/A51.79m AGLOTBD/OTHH30 Jun 2027
Doha DevelopmentA-153251631.51N 0513402.63E - 251623.51N 0513406.20E - 251624.47N 0513408.89E - 251616.54N 0513412.36E - 251615.61N 0513412.54E - 251614.95N 0513412.44E - 251614.23N 0513412.10E - 251613.51N 0513411.42E - 251609.85N 0513413.05E - 251609.66N 0513412.89E - 251608.65N 0513413.34E - 251603.68N 0513359.84E - 251615.70N 0513354.52E - 251615.90N 0513353.82E - 251619.88N 0513351.36E - 251620.20N 0513351.34E - 251621.11N 0513350.95E - 251621.72N 0513350.57E - 251622.17N 0513350.20E - 251622.56N 0513350.02E - 251623.39N 0513352.32E - 251624.36N 0513354.66E - 251623.56N 0513355.02E - 251624.50N 0513355.03E - 251631.51N 0513402.63E.N/A35m AGLOTBD30 Jun 2027
Doha DevelopmentA-154251615.90N 0513353.82E - 251614.69N 0513350.52E - 251617.29N 0513349.37E - 251617.84N 0513350.89E - 251618.28N 0513350.70E - 251618.44N 0513351.13E - 251618.89N 0513351.31E - 251619.88N 0513351.36E - 251615.90N 0513353.82E.N/A22m AGLOTBD30 Jun 2027
A-161251623.86N 0513406.54E- 251613.06N 0513411.30E- 251610.23N 0513403.54E- 251621.62N 0513358.78E- 251623.86N 0513406.54E. N/A70m AGLOTBD30 Jun 2027
A-162251631.36N 0513402.58E - 251623.38N 0513406.13E - 251624.36N 0513408.82E - 251616.59N 0513412.22E - 251615.87N 0513410.25E - 251612.28N 0513411.84E - 251609.32N 0513403.72E - 251625.71N 0513356.49E - 251631.36N 0513402.58E.N/A55m AGLOTBD31 Jan 2028
A-163251607.88N 0513411.57E - 251611.59N 0513409.93E - 251612.28N 0513411.84E - 251608.58N 0513413.49E - 251607.88N 0513411.57E.N/A50m AGLOTBD31 Jan 2028
A-164251621.40N 0513350.87E - 251621.89N 0513352.22E - 251619.80N 0513353.13E - 251619.20N 0513351.43E - 251620.33N 0513351.42E - 251621.40N 0513350.87E.N/A50m AGLOTBD31 Jan 2028
(1) All coordinates are calculated data.
2.2 Attachment:
Attachment A - Doha and Hamad International airports

  -END-
